MillerTech EDISON 48V 5000W Solar Inverter Charger (485E)
MillerTech EDISON 48V 5000W Solar Inverter Charger (485E)
MillerTech's EDISON series of inverter chargers for solar applications are built for light duty, non-commercial applications. This makes them perfect for solar hobbyists or small to medium sized off-grid projects.
Combining a solar charge controller, pure sine wave inverter, and AC charger in one device, the 485E is ideal for any 48V solar panel system under 5000W of solar input power.
*This unit can provide peak power of 10000VA and is capable of starting a motor up to 4HP, such as a large well pump*
48V 5000W Solar Inverter Charger (485E) Specifications:
AC INPUT
- Rated Input: 90-140V AC @ 47-65Hz
- Overload Protection: Breaker
- Efficiency: >95%
- Conversion Time (Bypass & Inverting): 10ms
- AC Reverse Flow Protection: Yes
- Max AC Bypass Current: 63A
INVERTING MODE
- Wave Form: Pure sine wave
- Continuous Output: 5000VA/5000W
- Peak Output: 10000VA/10000W
- Output Voltage: 120V AC +/- 5%
- Output Frequency: 50Hz/60Hz
- Power Factor: 1
- Rated Output Current: 50A
- Efficiency: >90%
- Overload Protection: 2-10% overload = shutdown after 5 minutes; 10-25% overload = shutdown after 10 seconds; 25% or more overload = shutdown after 5 seconds
- Loaded Motor Capacity: 4HP
- Output Short-Circuit Protection: Breaker
- Bypass Breaker Current: 63A
- Rated Battery Input Voltage: 48V DC nominal (40-66V DC range)
- Protections: Undervoltage alarm, turnoff voltage, overvoltage alarm, overvoltage restoration, programmable LCD screen
- Power Saving Mode: <50W load
AC CHARGER MODE
- Compatible Battery Types: Lithium or lead acid
- Maximum Charge Current: 40A (+/- 5A)
- Charge Voltage Range: 40-60V DC
- Short-Circuit Protection: Breaker and blown fuse
- Breaker: 63A
- Overcharge Protection: Turn off charge after 1 minute
SOLAR INPUT (SOLAR CHARGE CONTROLLER)
- Maximum PV Open-Circuit Voltage: 500V DC
- PV Operating Voltage Range: 120-500V DC
- Maximum Input Wattage: 5000W
- Maximum Input Current: 80A
- Charge Short-Circuit Protection: Blown fuse
- Protection: Inverse wiring
CERTIFICATIONS & OTHER
- Operating Temperature Range: -10C-55C
- Intrusion Protection (Dust & Moisture): IP20
- Certifications: CE (IEC 62109-1), CETL (UL1741/CSA C22.2 No. 107.1)
- EMC Authentication: EN61000
- Weight: 11.6kg
- Thermal Dissipation: Forced air (adjustable speed)
- Dimensions: 426mm x 322mm x 126mm
- Communication Interfaces: USB, RS485, WiFi, GPRS, dry node control
**For indoor installation only**
